EASY CLEAN AND FIREPROOF
Full steel cabinet and stainless steel air inlet covers, rust-proof and easy clean;
EASY OPERATION
Selectable high and lower air velocity controlled by remote control or key switch.
RECESSED IN CEILING DESIGN
Recessed in ceiling or hang on ceiling type design, its for special situations where the glass door is unable or lacks of enough space for side installation.
Apply high velocity motor, centrifugal turbine fan and scientific air duct design; powerful air pressure and lower noise operation;
Functional Details
| Model | Unit (mm) | Voltage (V~) | Frequency (Hz) | Air velocity (m/s) | Air volume (m3/h) | Noise (dB) | Power (W) | Net weight (kg) | Unit size (mm) |
|---|---|---|---|---|---|---|---|---|---|
| FRX-4009CS/Y | 900 | 220 | 50/60 | 16 | 1100 | 49 | 230 | 17 | 900x235x320 |
| FRX-4012CS/Y | 1200 | 220 | 50/60 | 16 | 1500 | 50 | 290 | 22 | 1200x235x320 |
| FRX-4015CS/Y | 1500 | 220 | 50/60 | 16 | 1900 | 52 | 380 | 27 | 1500x235x320 |
| FRX-4018CS/Y | 1800 | 220 | 50/60 | 20 | 2300 | 55 | 400 | 32 | 1800x235x320 |
| FRX-4020CS/Y | 2000 | 220 | 50/60 | 24 | 2800 | 58 | 420 | 38 | 2000x235x320 |
