Application: for high grade restaurants, offices, shopping malls, hotels and commercial buildings etc.
FASHION DESIGN
Outside cover without screw, patent design of arc shape appearance, compact & fashion.
EASY OPERATION
Available with remote control and key switch; with selectable high and lower air velocity.
CENTRIFUGAL FAN MOTOR
Low noise centrifugal fan, with high air pressure and adjustable air direction.
LUXURY MATERIALS
By aluminum cover body and combine with high precise ABS, never rusty and easy disassembly; high velocity motor can operate continuously 5000h without failure.
Functional Details
| Model | Unit (mm) | Voltage (V~) | Frequency (Hz) | Air velocity (m/s) | Air volume (m3/h) | Noise (dB) | Power (W) | Net weight (kg) | Unit size (mm) |
|---|---|---|---|---|---|---|---|---|---|
| FRX-4009-L/Y | 900 | 220-240 | 50/60 | 20 | 1400 | 54 | 300 | 13 | 900x215x230 |
| FRX-4012-L/Y | 1200 | 220-240 | 50/60 | 20 | 1900 | 55 | 400 | 15.5 | 1200x215x230 |
| FRX-4015-L/Y | 1500 | 220-240 | 50/60 | 20 | 2300 | 58 | 500 | 20 | 1500x215x230 |
| FRX-4018-L/Y | 1800 | 220-240 | 50/60 | 20 | 2800 | 59 | 600 | 24 | 1800x215x230 |
| FRX-4020-L/Y | 2000 | 220-240 | 50/60 | 20 | 3300 | 61 | 700 | 32 | 2000x215x230 |
