HIGH QUALITY PERFORMANCE
Patent design and upgraded performance, good appearance and better quality.
AIR DUCT INNOVATION
Combine the advantage of cross-flow and centrifugal air duct, obtained the high air volume and high air velocity at the same time.
LUXURY MATERIALS
High efficient motor with thermal protector can operate continuously 5000h without failure. Higher air volume with superior performance.
EASY OPERATION
Special design of air deflection vane enables to adjust the air direction easily. Two speeds controlled by the remote control or key switch.
CHARMING DESIGN
Silver aluminum sandblast shell, 3D shape design, newly aluminum bar air intake panel.
Functional Details
| Frequency (Hz) | Air velocity (m/s) | Air volume (m3/h) | Noise (dB) | Power (W) | Net weight (kg) | Unit size (mm) |
|||
|---|---|---|---|---|---|---|---|---|---|
| FRX-1209T/YDN | 900 | 220-240 | 50/60 | 11 | 1400 | 55 | 160 | 10 | 900x190x225 |
| FRX-1212T/YDN | 1200 | 220-240 | 50/60 | 11 | 1900 | 56 | 200 | 12.5 | 1200x190x225 |
| FRX-1215T/YDN | 1500 | 220-240 | 50/60 | 11 | 2500 | 57 | 230 | 15.5 | 1500x190x225 |
| FRX-1218T/YDN | 1800 | 220-240 | 50/60 | 11 | 3200 | 58 | 300 | 18 | 1800x190x225 |
| FRX-1220T/YDN | 2000 | 220-240 | 50/60 | 11 | 3600 | 59 | 350 | 20 | 2000x190x225 |
